MRCOOL VersaPro 24,000 BTU 2-Ton 16.7 SEER2 R-410A Central Ducted Heat Pump Condenser 208/230V MVP-24-HP-C-230-25
Questions? Call Us Today
Call Us on (888)-897-6153
Elevate your home comfort experience affordably with the 2 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser. This innovative solution not only offers superior year-round heating and cooling but also saves you money, both on utility bills and installation costs. Equipped with a DC inverter and variable speed compressor, it achieves an impressive SEER2 rating of 16.7, ensuring efficient performance. In addition to its efficiency, the condenser makes for a quiet and effective heating and cooling solution that avoids costly and time-consuming duct work installation. Paired with compatible MRCOOL air handlers and existing ductwork, this unit is sure to provide dependable home comfort for years to come.
Key Features
- DC inverter variable speed compressor for maximum efficiency
- 16.7 SEER2 energy efficiency rating
- R-410A refrigerant
- AHRI certified
- App compatible for smart control
- Professional installation required
Technical Specifications
| Cooling Capacity | 24,000 BTU |
| Heating Capacity | 24,000 BTU |
| Tonnage | 2 Ton |
| SEER2 | 16.7 |
| EER2 | 11.7 |
| HSPF2 | 9.1 |
| Voltage | 208-230 V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse/Breaker | 35 A |
| Min Circuit Ampacity | 22 A |
| Refrigerant Type | R-410A |
| Refrigerant Volume | 81.0 oz |
| Sound Level | 58 dBA |
| Liquid Line Size | 3/8 |
| Suction Line Size | 5/8 |
| Compressor Type | Twin-Rotary |
| Net Weight | 125.22 lbs |
| Net Dimensions (D×H×W) | 16.14" × 31.89" × 37.24" |
| Gross Weight | 143.74 lbs |
| GTIN / UPC | 00840255577489 |
| AHRI Certified | Yes |
Product Documentation
- MRCOOL VersaPro 24,000 BTU 2-Ton Heat Pump Condenser Brochure (PDF)
- MRCOOL VersaPro 24,000 BTU 2-Ton Heat Pump Condenser Installation Manual (PDF)
- MRCOOL VersaPro 24,000 BTU 2-Ton Heat Pump Condenser Performance Specifications (PDF)
- MRCOOL VersaPro 24,000 BTU 2-Ton Heat Pump Condenser Warranty Document (PDF)
