MRCOOL 48K BTU Hyper Heat Central Ducted Heat Pump Condenser CENTRAL-48-HP-C-230A00
48K BTU Hyper Heat Central Ducted Heat Pump Condenser
A superb option to replace your outdated, cumbersome heating and cooling system, the 48K BTU MRCOOL® Hyper Heat Central Ducted Heat Pump Condenser delivers reliable climate control without straining your budget.
Equipped with a DC Inverter and advanced variable speed technology, this unit boasts exceptional efficiency, leading to significant utility cost reductions without compromising performance.
It features an impressive SEER2 rating of up to 15.6 and an HSPF2-4 rating of up to 9.4, thanks to its superior heating capacity. It ensures indoor comfort even when outdoor temperatures plunge to -22°F or climb to 122°F.
Installation is a cinch for professional HVAC technicians using the compatible MRCOOL® No-Vac® Quick Connect® Line Set. This distinctive line set eliminates the need for vacuuming or flare welding and is kink-resistant, streamlining the connection process and lowering installation expenses. In addition, the unit utilizes the eco-friendly R-410A refrigerant, causing no harm to the environment.
Constructed with premium materials like painted galvanized steel, this durable unit resists damage from severe weather, animals, or yard equipment, ensuring reliable performance for years to come.
In the rare event of any issues, a 10-year warranty covering the compressor, parts, and labor backs the unit. What's more, the labor warranty is automatically activated upon installation, removing the need for a lengthy registration process.
Specifications
|
SEER2 |
15.6 |
|
EER2 |
8.2 |
|
HSPF2-4 |
9.4 |
|
HSPF2-5 |
7.7 |
|
CFM |
4411.76 |
|
COOLING CAPACITY (BTU) |
47000 |
|
HEATING CAPACITY (BTU) |
50000 |
|
VOLTAGE (V) |
208-230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER (A) |
50 |
|
MIN CIRCUIT AMPACITY (A) |
42 |
|
REFRIGERANT TYPE |
R-410A |
|
REFRIGERANT VOLUME (OZ) |
169.32 |
|
DECIBEL RATING (DBA) |
64 |
|
INVERTER |
DC |
|
MAX LINESET LENGTH (FT) |
213.25 |
|
LIQUID LINE SIZE |
3/8 |
|
SUCTION LINE SIZE |
3/4 |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
Yes |
|
UL LISTED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
BASE WARRANTY |
10yrs Parts and Labor |
|
PROPOSITION 65 WARNING |
Yes |
|
NET DEPTH (IN) |
16.34 |
|
NET HEIGHT (IN) |
52.48 |
|
NET WIDTH (IN) |
37.48 |
|
NET WEIGHT (LBS) |
220.24 |
|
GROSS DEPTH (IN) |
19.49 |
|
GROSS HEIGHT (IN) |
57.48 |
|
GROSS WIDTH (IN) |
43.11 |
|
GROSS WEIGHT (LBS) |
249 |
