MRCOOL Hyper Heat 2nd Gen 30,000 BTU 2.5-Ton 16.8 SEER2 R-454B Central Ducted Heat Pump Condenser 208/230V CENTRAL-30-HP-C-230B00-O
by MRCOOL
Original price
$2,283.00
-
Original price
$2,283.00
Original price
$2,283.00
$2,283.00
-
$2,283.00
Current price
$2,283.00
Questions? Call Us Today
Call Us on (888)-897-6153
Elevate your home into a haven of comfort with the 30K MRCOOL® Hyper Heat Central Ducted Condenser, crafted to excel in the most demanding weather conditions. Powered by R-454B refrigerant and backed by a 10-year warranty on parts, compressor, and labor, this unit delivers consistent Hyper Heat performance for your ducted system.
Key Features
- R-454B refrigerant for lower environmental impact
- Hyper Heat technology for reliable heating in extreme cold
- Wi-Fi and app compatible for smart control
- Energy Star certified
- AHRI certified
- ETL certified
- 10-year parts, compressor, and labor warranty
Technical Specifications
| Cooling Capacity | 30,000 BTU |
| Heating Capacity | 34,000 BTU |
| SEER2 | 16.8 |
| EER2 | 11.7 |
| HSPF (4-Zone) | 10.0 |
| Tonnage | 2.5 Ton |
| Voltage | 208-230 V |
| Phase | 1 |
| Frequency | 60 Hz |
| Max Fuse/Breaker | 30 A |
| Min Circuit Ampacity | 29.5 A |
| Refrigerant Type | R-454B |
| Refrigerant Volume | 105.82 oz |
| Sound Level | 60.5 dBA |
| Liquid Line Size | 3/8 |
| Suction Line Size | 3/4 |
| Net Weight | 164.02 lbs |
| Net Dimensions (D×H×W) | 16.14" × 31.89" × 37.24" |
| Gross Weight | 174.6 lbs |
| Gross Dimensions (D×H×W) | 19.68" × 34.84" × 42.91" |
| GTIN / UPC | 00840255586511 |
| Energy Star Certified | Yes |
| AHRI Certified | Yes |
| Warranty | 10 Years Parts / 10 Years Compressor / 10 Years Labor |
Product Documentation
- MRCOOL Hyper Heat 2nd Gen 30,000 BTU Central Ducted Condenser Brochure (PDF)
- MRCOOL Hyper Heat 2nd Gen 30,000 BTU Central Ducted Condenser Installation Manual (PDF)
- MRCOOL Hyper Heat 2nd Gen 30,000 BTU Central Ducted Condenser Performance Specifications (PDF)
- MRCOOL Hyper Heat 2nd Gen 30,000 BTU Central Ducted Condenser Service Manual (PDF)
- MRCOOL Hyper Heat 2nd Gen 30,000 BTU Central Ducted Condenser Warranty Document (PDF)
